Product Description
Active Nearfield Monitor
- Tweeter with a low directivity for a flexible listening position
- Closed design with 2 passive diaphragms for easy positioning anywhere near a wall
- 2.5-Way design for optimal control of the basses and lower midrange
- Optimal integration via comprehensive settings
- Flax sandwich diaphragm for a controlled and defined bass reproduction and natural and detailed lower and upper mids
Technical specifications:
- Frequency response (+/- 3 dB): 40 Hz to 35 kHz
- Max. sound pressure level (music): 110.5 dB SPL (sound pressure level) (peak @ 1m)
- Electronics inputs/impedance type: XLR: balanced, 10 kOhm
- RCA connectors: unbalanced, 10 kOhm with compensation of the input sensitivity
- Power amp for the mid- and bass range: 2x 80W, Class AB
- Power amp for the treble range: 50 W, Class AB
- Automatic standby mode
- Shutdown after about 30 minutes without an input signal
- Exit standby mode: Via signal > 3 mV
- Power supply voltage: 220 to 240 V (fuse: T2AL/250 V) or 100 to 120 V (fuse: T3.15AL/250 V)
- Connections: IEC socket and separate power cable
- High-pass filter: Variable, range 45/60/90 Hz
- Bass level (0 – 250 Hz): Variable, +/- 6 dB
- Mid/Bass (160 Hz, Q = 1): Variable, +/- 3 dB
- Treble level (4.5 – 35 kHz): Variable, +/- 3 dB
- Power on/off: ON/OFF switch on the back
- Power consumption in standby mode: < 0.5 W
- LED for power on/off and standby
- Woofer: 2 x 5″ (13 cm) flax cone woofer
- Tweeter: 1″ (25 mm) aluminium/magnesium with M-profile
- Housing structure: 15 mm MDF
- Finish: Vinyl, walnut veneer, black lacquer
- Dimensions with 4 rubber feet (H x W x D): 478 x 211 x 279 mm
- Weight: 11 kg
